Clack
Control valve, Vanne clack twin ci ws1, Clack CLACK-VTT1CIDME-03
Part number ART090843 · Valves
Net prices excl. VAT and ordering are reserved for signed-in professional accounts.
Control valve Clack CLACK-VTT1CIDME-03. Control valve for softener or filter (service and regeneration cycles: backwash, brine draw, rinse). Specification: Vanne clack twin ci ws1. Genuine Clack ref., compatible with softeners and filters; fast resupply at DIMM.
The valve acts as the primary hub that controls and regulates all water softening or filtration cycles. It can be set to do a down recovery or simply wash and rinse.
- Clock or counted
- Easy programming
- Piston type valve
- Easy to maintain
- Manually added salt alarm
All WS1 valves are equipped with a transformer 220/240, 12 volt European adapter and a 4.5 meter power cord.
All WS1 valves standard with white injector and DLFC ¾”, 2.7 gpm (10” tank size)
- Service flow rate at 1 bar drop 6.1 m³/h
- Backwash at 1.7 bar pressure 6.1 m³/h
- Working pressure from 1.5 to 8.5 bar
- Water temperature from 4°C to 43°C
- Tank thread 2.5 inches
