Straight Male Connector John Guest 3/8" × 1/4" | PI011202S
Part number ART090893 · Fittings
Net prices excl. VAT and ordering are reserved for signed-in professional accounts.
John Guest straight reducing connector 3/8" × 1/4"
Straight John Guest fitting combining a 3/8" male stem with a 1/4" push-fit connector. It reduces between two tubing diameters, or links an existing 3/8" fitting directly to a 1/4" line.
How it fits
The 3/8" male stem is sized to the outside diameter of tube: it plugs straight into a 3/8" push-fit fitting, exactly as the tube itself would. On the 1/4" side, the tube pushes into the collet, which locks it automatically.
The result: no tools, no seals to fit, no glue. The joint releases by pressing the collar, which makes servicing straightforward.
Where to use it
Reduction at an RO system outlet, transition from a 3/8" feed to a 1/4" distribution line, connection of a tank, solenoid valve or dispensing tap. Useful anywhere two components of the same installation do not share the same tubing diameter.
John Guest quality
John Guest fittings are the reference for push-fit on water treatment installations: stainless steel locking collet, integrated O-ring, food-grade polymer body. They hold pressure without creep and take repeated disconnection cycles without losing their seal.
Fitting
Cut the 1/4" tube square with a proper tube cutter for a clean section, then push it fully home to the stop. Pull gently to confirm it has locked. Pressurise and check for leaks before closing up the installation.
John Guest reference PI011202S.
